Alba EPM 1000 Construction Hoist – Rack & Pinion

The EPM 1000 Construction Hoist is easy to install and suitable for confined spaces. The high quality, compact design of the EPM 1000 rack & pinion construction hoist comes at an economical price. It utilizes the Alba triangle masts, allowing it to carry higher capacity loads compared to other compact personnel hoists. Its call control system can be set up and programmed by floor on the job site allowing for ease of use by workers. In addition, a version for lifting drywall with a slightly longer cabin is available upon request.

• Overspeed parachute with auto-recovery system
• Galvanized steel construction with a non-slip cage floor is durable and stands up to rough handling
• Hoist controls with LED display
• Soft start and stop is gentle on materials and personnel
• Industry-leading safety features, such as: Upper and lower limit switches, Overspeed safety device, Controlled descent device­, Overload safety stop, Proximity safety switch

Max. load capacity: 2200 lb (1000 kg)
Max. speed: 66 ft/min (20 m/min)
Max. height: 400 ft (120 m) (inquire about greater heights)
Cabin dimensions: 10’ 6’’ x 4’ 7’’ x 6’ 11’’ (3.2 m x 1.4 m x 2.1 m)
Mast section: Triangle (Length: 59” (1.5 m)    Weight: 104 lb (47 kg))
Mast section compatibility: Transport Platform: PT 1200  |  Material Hoist: MC 1000  |  Mast Climber: PEC 120
