Fixator

Fixator m.Lift 400 Manual Hoist

860409
inquire
Product information

The m.lift 400 Manual Traction Hoist has unrestricted lifting height and adapts to all types of suspended platforms, bosuns chairs and work cages.

The compact size and light weight makes it easy to handle. Installation and operation is simple and intuitive. The hand crank mechanism is smooth and comfortable to use.

For safety, the m.lift 400 has an automatic brake system and a built-in fall prevention safety device for the suspension wire rope. An optional second wire rope can be used with the built-in second wire rope safety device (mandatory when using multi-tier platforms).

  • Built-in primary and second wire rope brakes, no extra bolt-on devices needed
  • Compact and light weight
  • Simple and comfortable to operate
  • Adaptable to all kinds of platforms, work cages and bosuns chairs
  • Durable construction for long life span
  • Stainless Steel version for marine environment



Specifications

  • Load Capacity: 900 lb (400 kg)
  • Wire Rope Diameter: 8.3 mm
  • Dimensions HxWxD: 17x8x9.5 in. (430x200x240 mm)
  • Weight: 24.3 lb (11 kg)
  • Construction: Cast aluminum and steel (optional stainless steel)
